Name: 2025 Honda Pioneer 1000-5 Trail Special Edition - Fuel1Direct
Price: 25599.00 USD
Availability: InStock

General Information

Manufacturer

Honda

Model Year

2025

Model

Pioneer 1000-5 Trail Special Edition

Model Code

SXS10M5SE

Stock Number

N/A

Color

Matte Gray Metallic

Brakes/Wheels/Tires

Brakes

Front / Rear – Dual 210 mm hydraulic discs

Tires

Front – 27 x 9-14

Rear – 27 x 11-14

Dimensions

Length

119.2 in.

Height

76.5 in.

Width

63.0 in.

Weight

Curb – 1,777 lb. (Includes all standard equipment, required fluids and full tank of fuel)

Ground Clearance

12.3 in.

Wheelbase

80.2 in.

Seat Height

33.8 in.

Turning Radius

13.8 ft.

Drivetrain

Transmission

Six-speed automatic Dual-Clutch Transmission (DCT)

Drive System

Driveline – Direct front and rear driveshafts

Engine

Unicam® SOHC; four valves per cylinder, longitudinally mounted parallel-twin four-stroke

Cooling

Liquid

Displacement

999 cc

Bore x Stroke

3.6 x 3 in. (92 x 75.2 mm)

Compression Ratio

10:1

Fuel System

Fuel Injection (PGM-FI); 44 mm throttle body

Fuel Capacity

7.9 gal. (including 1.7 gal. reserve)

Operational

Front Suspension

Independent double-wishbone

Travel – 10.6 in.

Rear Suspension

Independent double-wishbone

Travel – 10 in.

Other

Cargo Box Capacity

1,000 lb.

Towing Capacity

2,500 lb.

Safety Features

Recommended for drivers 16 years of age and older

Warranty

One year, transferable, limited
