500 Liter Double Walled Self Bunded Diesel Tank

SUMAC Auto Recycling Equipment Co.,Ltd is one of the most professional manufacturers and suppliers of 500 liter double walled self bunded diesel tank in China. Please feel free to buy high quality 500 liter double walled self bunded diesel tank at competitive price from our factory. Introduction

500 Liter double walled self bunded diesel tank

Coolant, waste fuel, diesel, gasoline, waste oil, and any other liquid that isn’t flammable at room temperature can all be distributed and stored in fuel storage tanks.
Since all connections are done through the top, there is less possibility of leakage into the surrounding area because of the double-wall design’s self-binding properties.
Due to the gasoline storage tank’s special outlet configuration, no sediment of any kind can accumulate on the floor from the inside. The self-adhesive tanks, which are fully designed and produced by SUMAC, are painted surfaces and constructed to industry standards of quality.
For long-term fuel/oil storage applications, a rectangular fuel storage tank design optimizes storage capacity while preserving full self-bundling tank visibility.

Specification

Model

ARST-500

Material

Carbon steel

Tank type

Storage and dispensing

Size

1105x710x1270mm

Volume

500 litres

Empty Weight

About 284kg

Test pressure

About 35Kpa

Feed/Discharging

DN40

Application

Waste fuel, petrol, waste oil, diesel, coolant, Any liquid,

other than a flammable liquid under normal temperature.

Comes With

· Meet strict quality standards, CE approved.

· All seams are welded to exacting standards.

· 2 Way forklift pockets.

· The tanks fit with SUMAC supplied free vent, gravity outlet valve and dipstick.

· Designed to be stacked for storage and transport empty, and with 1pc lockable lids.

· Supplied with all required statutory decals. We can also customize logo according to customer needs.

· Can be lifted via forklift to ensure ease of access and maneuverability, as well as lifting eyes at each corner.

· Removable lid – Easy maintenance and cleaning of carbon steel inner tank.

Tank Connections

Our Customers

About Us

FAQ

1.What is your standard configuration for connections

Fill Dip,Inlet,Fuel Gauge,Outlet: DN40.

E-Vent,FreVent: DN50.

2.Can we specify the colour of the tanks and are they painted or powder coated?

Yes, can specify colour, powder coated.

3.Is there any way to check for fluid between the skins (1st and 2nd layer)?

Oil tank with inspection port.

4.Can you confirm if the tanks are supplied with, dip stick & the vent?

Yes.

5.Is there a suction tube on the outlet port for evac of the waste oil?

Yes.

6.For the secondary sealing capacity, whether to increase the capacity of 10% on the basis of the inner tank capacity.

Yes.

Hot Tags: 500 liter double walled self bunded diesel tank, China 500 liter double walled self bunded diesel tank manufacturers, suppliers, factory
