Gasoline Petrol Cube Tank Bunded Diesel Fuel Tank Self Bunded Fuel Tank

SUMAC Auto Recycling Equipment Co.,Ltd is one of the most professional manufacturers and suppliers of gasoline petrol cube tank bunded diesel fuel tank self bunded fuel tank in China. Please feel free to buy high quality gasoline petrol cube tank bunded diesel fuel tank self bunded fuel tank at competitive price from our factory. Introduction

Gasoline Petrol Cube Tank Bunded Diesel Fuel Tank Self Bunded Fuel Tank

Designed to connect to equipment and dispense fuel at the same time, Sumac Fuel tanks can give you more flexibility and save you valuable time. With two forklift pockets for mobility when empty, oil tank can move with you, wherever and whenever you need it. All connections are through the top and the double wall design makes them self bunded, eliminating the chance of leakage into the environment. Fuel tanks have a unique outlet arrangement that draws from the floor of the inner preventing build up of any type of sediment.

Technical Specification

Model

SU-1000L

Material

Carbon steel

Tank type

Storage and dispensing

Size

2100x1100x1120mm

Volume

1000 litres

Empty Weight

About 680kg

Test pressure

About 35Kpa

Feed/Discharging

1inch

Application

Waste fuel, petrol, waste oil, diesel, coolant, Any liquid,

other than a flammable liquid under normal temperature.

Comes With

· All seams are welded to exacting standards.

· 2 Way forklift pockets.

· Comes complete with fluid level dipstick, vent pipe and fittings.

· Lockable containment area for pump, hose and nozzle storage.

· The number of standard feed and return line ports allow for the connection of up to 3 x generators or industrial equipment simultaneously.

· Can be lifted via forklift to ensure ease of access and maneuverability, as well as lifting eyes at each corner.

· Removable lid – Easy maintenance and cleaning of carbon steel inner tank.

· Supplied with all required statutory decals. We can also customize logo according to customer needs.

Related Fittings

About Sumac

Our Customers

Application

FAQ

Q. What is your standard configuration for connections?

A. Fill Dip, Inlet, Fuel Gauge, Outlet: DN25 or customized; E-Vent, FreVent: DN50

Q. Can we specify the colour of the tanks and are they painted or powder coated?

A. Yes, can specify colour, and our tanks are powder coated.

Q. Is there any way to check for fluid between the skins (1st and 2nd layer)?

A. Oil tank with inspection port.

Q. Is there a suction tube on the outlet port for evac of the waste oil?

A. Yes.

Q. For the secondary sealing capacity, whether to increase the capacity of 10% on the basis of the inner tank capacity.

A. Yes.

Q: Are your oil tanks rust-proof?

A: Yes, our paint is electrostatic spraying of polyester powder, we called powder coating paint, oil resistance, antirust treatment.

Q: Is the fuel tank easy for land transport?

A: Yes.

Q: Does the fuel tank has lockable cabinets for pump?

A: Yes.

Q: Can it come with fuel pump?

A: Yes, we can equip with different kinds of fuel pump according to customer needs.
