Portable Fuel Gasoline Diesel Cube Tank For On-Site Refueling

SUMAC Auto Recycling Equipment Co.,Ltd is one of the most professional manufacturers and suppliers of portable fuel gasoline diesel cube tank for on-site refueling in China. Please feel free to buy high quality portable fuel gasoline diesel cube tank for on-site refueling at competitive price from our factory. Product Introduction

Portable Fuel Gasoline Diesel Cube Tank For On-Site Refueling

Designed to connect to equipment and dispense fuel at the same time, Sumac Fuel cube tanks can give you more flexibility and save you valuable time. With two forklift pockets for mobility when empty, oil tank can move with you, wherever and whenever you need it.

If you’re working on a site with limited access, this tank from Sumac is your portable tank, a fully transportable fuel storage solution that increases productivity.

NW Series Fuel cube tanks with fuel dispensing machine, are the most popular products in the world, which offer a flexible solution to storing combustible liquid (Diesel, gasoline, oil, coolant, etc. ) , as well as improving fuel dispensing and management solutions.

Technical Parameters

Model

NW-1000

NW-2000

NW-3000

NW-4000

NW-5000

Material

Carbon steel, double wall

Tank type

Storage and dispensing

Size mm

1145x1140x1300
2320x1145x1285
1570x2320x1285

2337x2337x1143

2337x2311x1321

Capacity

(Normal/Safe fill (95%), L)

950/900

2090/1987

2980/2831

3785/3596

4600/4368

Empty Weight (Kg)

About 440

About 824

About 1042

About 1580

About 1690

Test pressure (Kpa)

About 35

Fill Dip, Inlet, Fuel Gauge, Outlet

DN40

E-Vent, Free Vent

DN50

Application

Waste fuel, petrol, waste oil, diesel, coolant, Any liquid,

other than a flammable liquid under normal temperature.

Come With

Meet strict quality standards, CE approved.

All seams are welded to exacting standards.

4 x way forklift pockets – Quick and easy maneuvering and mobility.

The tanks come complete with fluid level dipstick, vent pipe and fittings.

Stackable, and with 1pc lockable lids and maintenance hole.

Supplied with all required statutory decals.

Lockable containment area for pump, hose and nozzle storage.

Designed to be stacked for storage and transport empty.

Can be lifted via forklift to ensure ease of access and maneuverability, as well as lifting eyes at each corner.

Removable lid – Easy maintenance and cleaning of carbon steel inner tank.

Product Detailes

Packing & Shipping

Company Profile

FAQ

What is your standard configuration for connections?

Fill Dip,Inlet,Fuel Gauge,Outlet: DN25.

E-Vent,Free Vent: DN50.

Can we specify the colour of the tanks and are they painted or powder coated?

Yes, can specify colour, powder coated.

Is there any way to check for fluid between the skins (1st and 2nd layer)?

Oil tank with inspection port.

Is there a suction tube on the outlet port for evac of the waste oil?

Yes.

For the secondary sealing capacity, whether to increase the capacity of 10% on the basis of the inner tank capacity.

Yes.
